To be installed on
Dimensions (mm)
E
F
G
H
SEMISOM HS - HA
328 163 15 80
SEMISOM 635 HS - HA
348 180 47 97
ILLUSTRATION OF AN INSTALLATION WITH GUIDE RAIL KIT
|
|
