106 / 132
B
A
DNM
D
C
106
Electric submersible pumps SEMISOM GR
for sewage water with grinder
Grinder
Code
Version
P2 Max
µF DNM
Q
Flow
Dimensions (mm) Weight
hp kW A
m
3
/h 0 1,2 2,4 3,6 4,8 6 6,6
A B C D kg
l/min 0 20 40 60 80 100 110
SEMISOM
125 GR
(no stands)
SMZ125 230 V 1-phase
1,6 1,18
9,2 25
1"½
H
(m)
30 27,5 25,5 22,5 19 14 3
416
29 240 190
22
SMZ125+G 230 V 1-phase+float
22,2
STZ125 400 V 3-phase
2,9
396
21,2
SEMISOM
125 GR
(with stands)
SMZ125P 230 V 1-phase
1,6 1,18
9,2 25
1"½
H
(m)
30 27,5 25,5 22,5 19 14 3
441
54 240 190
22,1
SMZ125+GP 230 V 1-phase+float
22,3
STZ125P 400 V 3-phase
2,9
421
21,3
Supplied with
10 meters power cable
Junction box containing starting capacitor,
unipolar thermal protector switch and facility
to connect an extra 50 μF start-run capacitor
(single-phase versions)
Code
Description
02410016
90° zinc-plated elbow 1"½ M/F
(to connect to the lifting station
Semibox)
02008200 Start-run capacitor 50 µF
04105042 Guide rail kit DNM 1"½
(¾" guide poles not included)
ACCESSORIes
PERFORMANCE DATA 2 poles 60 Hz
