112 / 132
B
A
D
C
DNM
235
112
Electric submersible pumps SEMISOM /50
for sewage water
Vortex Impeller
Code
Version
P2 P1 Max
Flow
Ø
solids DNM
Dimensions (mm) Weight
hp kW kW A
l/min
m
A B C D kg
SEMISOM
500/50
SMZ/50/500/1 230 V 1-phase
1,5 1,1
1,84 8,9
100 - 300 - 500 10 - 8 - 3 50 2"
518
70 354 254
32
SMZ/50/500+G/1 230 V 1-phase+float
32,3
STZ/50/500/1 400 V 3-phase
1,63 3,3
508
30,5
SEMISOM
800/50
SMZ/50/800/1 230 V 1-phase
2 1,5
2,21 10,4
100 - 300 - 600 11 - 9 - 3 50 2"½
543
70 362 254
34,5
SMZ/50/800+G/1 230 V 1-phase+float
34,8
STZ/50/800/1 400 V 3-phase
2,07 4
508
31
P1: Max. absorbed power - P2: Nominal power of the motor
Channel impeller
Code
Version
P2 P1 Max
Flow
Ø
solids DNM
Dimensions (mm) Weight
hp kW kW A
l/min
m
A B C D kg
SEMISOM
700/50
SMZ/50/700/1 230 V 1-phase
1,5 1,1
2,05 8,8
100 - 400 - 700 10 - 7 - 2 50 2"
518
70 354 254
32,5
SMZ/50/700+G/1 230 V 1-phase+float
32,8
STZ/50/700/1 400 V 3-phase
1,93 3,3
508
31
SEMISOM
900/50
SMZ/50/900/1 230 V 1-phase
2 1,5
2,6 11,2
100 - 500 - 1000 14 - 8,5 - 0 50 2"½
543
70 362 254
35
SMZ/50/900+G/1 230 V 1-phase+float
35,3
STZ/50/900/1 400 V 3-phase
2,39 4
508
31
SEMISOM
1000/50
STZ/50/1000/1 400 V 3-phase 3 2,2 3,33 5,9 100 - 500 - 1100 17,5 - 12 - 1 50 2"½ 543 70 362 254 35
P1: Max. absorbed power - P2: Nominal power of the motor
Supplied with
10 meters power cable
Control box containing capacitor and
illuminated thermal protector switch
(single-phase versions)
Options
Version with thermic probe so to protect
the motor from overheating
(to be wired to protection/control panel
type QT-MT - AM-AT)
PERFORMANCE DATA 2 poles 60 Hz
PERFORMANCE DATA 2 poles 60 Hz
