114 / 132
B
A
D
C
DNM
275
114
Electric submersible pumps SEMISOM /65
for sewage water
Vortex Impeller
Code
Version
P2 P1 Max
Flow
Ø
solids DNM
Dimensions (mm) Weight
hp kW kW A
l/min
m
A B C D kg
SEMISOM
1100/65
STZ/65/1100/1 400 V 3-phase 3 2,2 3,37 6 100 - 500 - 900 12,5 - 7 - 1,5 65 3" 584 65 417 222 40
SEMISOM
1300/65
STZ/65/1300/1 400 V 3-phase 4,5 3,4 5,1 8,1 100 - 600 - 1000 16,5 - 9 - 3 65 3" 609 65 417 222 42,5
P1: Max. absorbed power - P2: Nominal power of the motor
Vortex Impeller
Code
Version
P2 P1 Max
Flow
Ø
solids DNM
Dimensions (mm) Weight
hp kW kW A
l/min
m
A B C D kg
SEMISOM
754/65
SMZ/65/754/1 230 V 1-phase
1,6 1,2
1,55 7,7
100 - 400 - 800 7,8 - 5,5 - 2,1 65 3" 569 65 417 222
38,5
SMZ/65/754+G/1 230 V 1-phase+float
38,8
STZ/65/754/1 400 V 3-phase
1,45 3,3
38,5
P1: Max. absorbed power - P2: Nominal power of the motor
PERFORMANCE DATA 2 poles 60 Hz
PERFORMANCE DATA 4 poles 60 Hz
Supplied with
10 meters power cable
Control box containing capacitor and
illuminated thermal protector switch
(single-phase versions)
Options
Version with thermic probe so to protect
the motor from overheating
(to be wired to protection/control panel
type QT-MT - AM-AT)
