Photovoltaic pumping stations IDROSOLAR
Type
MOTOR
PUMP END
SUGGESTED SOLAR MODULES*
P2
H
Q
Number
of strings
Mudules
each string
Total number
of modules
from to
from to
hp
kW
m
l/min
IDROSOLAR 1200
1
0,75
13
90
10 175
1
5
5
IDROSOLAR 1800
1,8
1,35
13 122 10 225
1
7
7
IDROSOLAR 2800
2,8
2
11 188 10 300
1
11
11
IDROSOLAR 3600
3,6
2,7
12 245 10 350
1
14
14
IDROSOLAR 5500
5,5
4
9
295 20 1000
1
20
20
IDROSOLAR 7500
7,5
5,5
13 223 75 1000
2
13
26
IDROSOLAR 10000
10
7,5
17 250 75 1600
2
19
38
IDROSOLAR 12500
12,5
9,2
23 307 90 1000
3
18
54
IDROSOLAR 15000
15
11
13 361 90 2400
3
19
57
IDROSOLAR 20000
20
15
34 323 150 1600
4
18
72
IDROSOLAR 25000
25
18,5
19 383 150 2400
4
21
84
IDROSOLAR 30000
30
22
26 290 200 2400
5
20
100
IDROSOLAR 40000
40
30
32 190 400 2400
6
21
126
* The above calculations have been made considering
solar panels with the following specifications
• Open circuit voltage (Voc) < 40,5 V
• Maximum power voltage (Vmp) > 30,8 V
• Maximum power current (Imp) < 10 A
• Maximum power rating (Pmax) ≥ 280 Wp
PERFORMANCE CHARACTERISTICS
PUMP TYPE COMBINATIONS
Type
Construction
Application/materials
Electric submersible pumps IDROSOM for 4" boreholes
see page 27
see page 28 - 29
Electric submersible pumps IDROSAND for 6" boreholes
see page 41
see page 42 - 43
Electric submersible pumps for 8" boreholes
/
/
