34 / 132
34
C
B
DNM
A
Radial impeller
Pump
Code
Motor
Version
P2
A
Flow
DNM
Dimensions (mm) Cable Weight
Code Series
hp kW
l/min
m
A B C m kg
IDROSOM
7/100
P100/07
M4M15
S 230 V
1-phase
1,5 1,1
8
20 - 70 - 120 61 - 51 - 18 1"½
808 406
95
2 14,5
MYEZ4M15 E 220 V
8,3
788 386
1,7 13,6
M4T15
S 400 V
3-phase
2,9
778 376
2 13,2
MYEZ4T15 E 380 V
3,9
773 371
1,7 12,7
IDROSOM
9/100
P100/09
M4M20
S 230 V
1-phase
2 1,5
11
20 - 70 - 120 78 - 65 - 23 1"½
910 456
95
2 17
MYEZ4M20 E 220 V
10,8
890 436
1,7 15,3
M4T20
S 400 V
3-phase
3,8
860 406
2 14,8
MYEZ4T20 E 380 V
4,5
840 386
1,7 13,9
IDROSOM
14/100
P100/14
M4M30/2 S 230 V 1-phase
3 2,2
14
20 - 70 - 120 120 - 102 - 36 1"½
1090 506
95 2
19,6
M4T30
S 400 V 3-phase
5,4
1040 456
17,9
IDROSOM
18/100
P100/18 M4T40
S 400 V 3-phase 4 3 7 20 - 70 - 120 155 - 131 - 47 1"½ 1219 531 95 2 21,2
IDROSOM
27/100
P100/27 M4T55
S 400 V 3-phase 5,5 4 9,4 20 - 70 - 120 232 - 196 - 70 1"½ 1551 587 95 2 26,4
IDROSOM
36/100
P100/36 M4T75
S 400 V 3-phase 7,5 5,5 12 20 - 70 - 120 310 - 261 - 94 1"½ 1875 677 95 4 33
Motor and pump end can be supplied coupled exclusively with ”S" series motors
PERFORMANCE DATA - 2 poles 60 hz
Electric submersible pumps IDROSOM series 100
for 4" boreholes
Supplied with
Capacitor
(for single-phase versions, "S" series)
OPTIONS
10 meters cable
20 meters cable
30 meters cable
Available up to 1.1 kW single-phase and three-phase up to 3 kW
ACCESSORIES
Code
Description
05405031 Non-return threaded valve 1"½GAS
