38 / 132
38
C
B
DNM
A
Radial impeller
Pump
Code
Motor
Version
P2
A
Flow
DNM
Dimensions (mm) Cable Weight
Code Series
hp kW
l/min
m
A B C m kg
IDROSOM
6/250
P250/06
M4M30/2 S 230 V 1-phase
3 2,2
14
70 - 180 - 300 52 - 38 - 11 2"
976 506
95 2
18,8
M4T30
S 400 V 3-phase
5,4
926 456
17,1
IDROSOM
8/250
P250/08 M4T40
S 400 V 3-phase 4 3 7 70 - 180 - 300 69 - 51 - 12 2" 1080 531 95 2 20,3
IDROSOM
12/250
P250/12 M4T55
S 400 V 3-phase 5,5 4 9,4 70 - 180 - 300 103 - 77 - 18 2" 1294 587 95 2 24,6
IDROSOM
17/250
P250/17 M4T75
S 400 V 3-phase 7,5 5,5 12 70 - 180 - 300 143 - 107 - 20 2" 1625 677 95 4 31,3
IDROSOM
22/250
P250/22 M4T100 S 400 V 3-phase 10 7,5 16 70 - 180 - 300 185 - 139 - 25 2" 1902 757 95 4 35,7
Motor and pump end can be supplied coupled exclusively with ”S" series motors
PERFORMANCE DATA - 2 poles 60 hz
Electric submersible pumps IDROSOM series 250
for 4" boreholes
Supplied with
Capacitor
(for single-phase versions, "S" series)
OPTIONS
10 meters cable
20 meters cable
30 meters cable
Available up to 1.1 kW single-phase and three-phase up to 3 kW
ACCESSORIes
Code
Description
05405035 Non-return threaded valve 2" GAS
