7 / 132
7
10
10
0
20
20
30
45
30
40
60
90
50
Q=l/min
H=m
70
80
40
Electric submersible peripheral pumps TURBOSOM
for 6" boreholes
APPLICATION
To pump clear water from boreholes
To pressurize civil plants
Irrigation
APPLICATION FEATURES
APPLICATION RANGE
IP rating
IP68
Duty
Continuous S1
Max number of starts per hour
40
Max temperature of the liquid pumped (°C)
50
PH of the liquid pumped
6 - 10
Maximum sand content (g/m
3
)
20
Suitable for inverter drive
Three-phase
versions only
Suitable to operate horizontally
CONSTRUCTION
Single-stage pump with peripheral impeller
Coolant filled, asynchronous, rewindable electric AC motor with short circuit rotor. Insulation Class F
Resin-insulated cable kit to prevent penetration of water inside the motor
MATERIALS
Motor casing and tie-rods
Stainless Steel AISI304
Shaft
Stainless Steel AISI420B
Impeller, bolts and nuts
Brass OT58
Head, body and foot
Mechanical cast iron EN GJL-250
Seal rings
NBR rubber
Elastomers
NBR rubber
Cable
H07RN8-F Neoprene
