B
A
D
C
DNM
92
Vortex Impeller
Code
Version
P2 Max
Flow
Ø
solids DNM
Dimensions (mm) Weight
hp kW A
l/min
m
A B C D kg
SEMISOM
265 VS
SMZ265GH
230 V 1-phase
0,75 0,55
4,2
30 - 150 - 300 7,5 - 5 - 1,5 40 1"½ 400 50 230 162
14
SMZ265+GGH 230 V 1-phase+float
14,2
STZ265GH
400 V 3-phase
1,7
14
SEMISOM
390 VS
SMZ390
230 V 1-phase
1 0,75
5,5
100 - 250 - 500 8,5 - 6 - 1 50 2" 450 65 235 162
15,7
SMZ390+G
230 V 1-phase+float
15,9
STZ390
400 V 3-phase
2,3
15,7
SEMISOM
490 VS
SMZ490
230 V 1-phase
1,5 1,1
7,3
100 - 250 - 600 9,5 - 7,5 - 1 50 2" 474 65 235 162
16,5
SMZ490+G
230 V 1-phase+float
16,7
STZ490
400 V 3-phase
2,7
16,5
Electric submersible pumps SEMISOM series VS
for sewage water, vertical discharge
Vortex Impeller
Code
Version
P2
P1 Max
Flow
Ø
solids DNM
Dimensions (mm) Weight
hp kW kW A
l/min
m
A B C D kg
SEMISOM
265 VS
SF265
24 V DC
0,75 0,55 0,67 28 30 - 150 - 300 8 - 5,5 - 1 40 1"½ 400 50 230 162 13
P1: Max. absorbed power - P2: Nominal power of the motor
Code
Description
02076100 QDC electromechanical direct starter
(24 V DC versions)
Supplied with
5 meters power cable
Control box containing capacitor
and amperometric protection
(single-phase versions)
PERFORMANCE DATA 2 poles 60 Hz
PERFORMANCE DATA - 24 V DC
ACCESSORIes
