87 / 132
0
2
4
6
8
10
12
14
16
100 200 300 400 500 600
Q=l/min
H=m
87
To expel rain water, convey waste and sewage water from septic tanks
To pump liquids containing solids (vortex or double channel impeller) and filaments (double channel impeller)
To pump sewage keeping its biological process unchanged (Semisom 504 4 poles)
APPLICATION
1~230V - 3~400V versions: coolant filled, asynchronous, rewindable electric AC motor with short circuit rotor. Insulation Class F.
Windings with phase insulators to protect the motor from power peaks, as a guarantee of a highly-trustworthy product.
24V DC versions: with permanent magnets dry electric DC motor. Insulation Class F
Resin-insulated cable kit to prevent penetration of water inside the motor
Shafts machined on ball bearings and mechanical seals location
Double mechanical seal with oil-chamber in-between
CONSTRUCTION
IP rating
IP68
Duty (versions 1~230V - 3~400V)
Continuous S1
Duty (versions 24V DC)
Limited use S2
(60 minutes)
Maximum immersion depth (m)
20
Maximum number of starts per hour
40
Maximum temperature of the liquid
pumped versions 1~230V - 3~400V (°C)
50
Maximum temperature of the liquid
pumped versions 24V DC (°C)
35
PH of the liquid pumped
6 - 10
Density of the liquid pumped (kg/dm
3
)
<1,1
Suitable for inverter drive
Three-phase
versions only
CHARACTERISTICS
APPLICATION RANGE
Tie rods, handle, motor casing, bolts and nuts
Stainless Steel AISI304
Shaft
Stainless Steel AISI420B
Cover and volute
Mechanical cast iron EN GJL-250
Impeller
Mechanical cast iron EN GJL-200
Mechanical seal
Silicon carbide and alumina
Packing Ring
NBR rubber
Elastomers
NBR rubber
Cable
Neoprene H07RN8-F; 24V DC: Twin Batt
MATERIALs
Electric submersible pumps SEMISOM
for sewage water
