PERFORMANCE DATA - PUMP ENDS - 2 poles 60 Hz
Code
Voltage Number
of
phases
P2
Axial load Rotation Nominal
current
Start
current
Start
Torque
Efficiency
%
Power
factor
Size
of
cable
Length
of
cable
F
n
N
I
N
I
A
M
A
V
hp kW N min
-1
A
A
Nm
η
N
cos ø mm
2
m
WATER FILLED SUBMERSIBLE MOTORS for 6” boreholes
6TA125
M6TA125/2
400
3 12,5 9,2 8000 3410
20
84
450
80
0,83 4 x 4
3
6TA15
M6TA15GH/2
400
3 15 11 8000 3420 22,7
98
440
85
0,83 4 x 4
3
6TA20
M6TA20/2
400
3 20 15 18000 3460 29,5 118 504
85
0,86 4 x 4
3
6TA25
M6TA25/2
400
3 25 18,5 18000 3450 37,7 113 720
84
0,86 4 x 6
3
6TA30
M6TA30/2
400
3 30 22 18000 3480
44
127 900
86
0,85 4 x 6
3
6TA35
M6TA35/2
400
3 35 26 18000 3480
51
193 1000
88
0,82 4 x 6
3
6TA40
M6TA40/2
400
3 40 30 18000 3450 58,5 193 1000
87
0,86 4 x 6
3
6TA50
M6TA50/2
400
3 50 37 18000 3490
74
244 1220
89
0,88 4 x 6
3
Semi-axial impeller
P2
DNM
Q
Flow
m³/h 0 18 21 24 30 39 42 48 54 60 69 78
hp kW
l/min 0 300 350 400 500 650 700 800 900 1000 1150 1300
SERIES 700
IDROSAND+ 3/700
10 7,5 3"
H
(m)
60 50 48 46 41 31 27 17
IDROSAND+ 5/700
12,5 9,2 3"
101 83 80 77 69 51 44 28
IDROSAND+ 6/700
20 15 3"
121 100 96 93 82 62 53 34
IDROSAND+ 8/700
25 18,5 3"
161 133 129 123 110 82 71 45
IDROSAND+ 10/700
25 18,5 3"
201 166 161 154 137 103 88 56
IDROSAND+ 13/700
40 30 3"
262 216 209 201 178 133 115 73
IDROSAND+ 16/700
50 37 3"
322 266 257 247 219 164 141 90
SERIES 900
IDROSAND+ 2/900
10 7,5 3"
H
(m)
41
35 32 29 27 25 21 18 12 5
IDROSAND+ 3/900
15 11 3"
59
52 50 45 43 39 34 29 20 9
IDROSAND+ 4/900
20 15 3"
79
73 70 64 61 56 49 42 29 14
IDROSAND+ 5/900
25 18,5 3"
100
92 89 81 78 71 63 54 39 21
IDROSAND+ 6/900
25 18,5 3"
120
109 105 96 92 84 75 65 48 30
IDROSAND+ 8/900
40 30 3"
162
150 143 130 125 115 103 90 68 42
IDROSAND+ 10/900
50 37 3"
202
187 179 162 156 144 129 112 85 52
Electric pumps supplied with 4” 'S' series motors up to 7,5 kW
