50 / 132
50
B
A
C
DNM
Radial impeller
Pump
Code
Motor
Code
Version
P2
A
Flow
DNM
Dimensions (mm) Cable Weight
hp kW
l/min
m
A B C m kg
IDROSAND+ 4/400
P400/04 M4T75
400 V 3-phase 7,5 5,5 12 150 - 350 - 500 66 - 48 - 24 3" 1277 672 146 3 61,7
IDROSAND+ 5/400
P400/05 M4T100
400 V 3-phase 10 7,5 16 150 - 350 - 500 81 - 61 - 34 3" 1352 697 146 3 66,5
IDROSAND+ 6/400
P400/06 M4T100
400 V 3-phase 10 7,5 16 150 - 350 - 500 95 - 74 - 44 3" 1402 697 146 3 67,9
IDROSAND+ 7/400
P400/07 M6TA125/2 400 V 3-phase 12,5 9,2 20 150 - 350 - 500 117 - 87 - 53 3" 1477 722 146 3 71,8
IDROSAND+ 8/400
P400/08 M6TA20/2 400 V 3-phase 20 15 29,5 150 - 350 - 500 133 - 102 - 64 3" 1662 857 146 3 89,5
IDROSAND+ 10/400
P400/10 M6TA25/2 400 V 3-phase 25 18,5 37,7 150 - 350 - 500 167 - 123 - 78 3" 1802 897 146 3 96,8
IDROSAND+ 12/400
P400/12 M6TA25/2 400 V 3-phase 25 18,5 37,7 150 - 350 - 500 200 - 153 - 94 3" 1902 897 146 3 100,2
IDROSAND+ 15/400
P400/15 M6TA30/2 400 V 3-phase 30 22 44 150 - 350 - 500 250 - 198 - 124 3" 2152 997 146 3 115,6
IDROSAND+ 20/400
P400/20 M6TA40/2 400 V 3-phase 40 30 58,5 150 - 350 - 500 334 - 253 - 161 3" 2532 1127 146 3 140,3
Electric pumps supplied with 4” 'S' series motors up to 7,5 kW
PERFORMANCE DATA - 2 poles 60 hz
Electric submersible pumps IDROSAND+ series 400
for 6" boreholes
OPTIONS FOR 6" MOTORS
Version for star-delta motors 400/690 V
Version with brass motor body
