73 / 132
73
200 400 600
1700
Q=l/min
800 1000 1200 1400
20
0
40
60
80
120
160
100
H=m
140
APPLICATION
To pressurize civil, agricultural and industrial plants
Irrigation
CHARACTERISTICS
APPLICATION RANGE
IP rating
IP54
Duty
Continuous S1
Ambient temperature (°C)
-5/+40
Maximum number of starts per hour
20
Maximum temperature of the liquid
pumped (°C)
80
PH of the liquid pumped
6 - 10
To be installed in a sheltered place
MATERIALs
Suction body and discharge
Mechanical cast iron EN GJL-200
Pump casing, tie rods, bolt and nuts
Stainless steel AISI304
Shaft
Stainless steel AISI420B
Impellers and diffusers
Noryl®reinforced with fibre-glass, certified for drinking water
and AISI304 stainless steel wear rings
Coupling
Mechanical cast iron EN GJL-200
Guide ball bearing
Self-lubricating bronze
Mechanical seal
Graphite and alumina
Diffuser bush
Anti-friction rubber (series 700)
Inlet manifold
Zinc-plated steel
Discharge manifold
Zinc-plated steel
Base and frame
Zinc-plated steel
Automatic booster sets
