Automatic booster sets G-CV
Two electric pumps CV (three on request)
N° 2 pressure switches installed on the discharge manifold to start and stop the pumps automatically (alternating - duty-assist)
Inlet manifold with non-return check valves, ball valves and facilities for air feeders
Discharge manifold connected to the electric pumps via ball valves
Pressure gauge
The whole set is assembled on one frame
Plastic control panel containing:
• opening interlocked
• hand - off - auto selector switches, one each electric pump
• electronic card that allows level control, overload protection and alternating duty - assist run of the electric pumps
• 24 V transformer 230-400
• 24 V contactors
• set of fuses for motor protection
• fuses on auxiliary circuit
MAIN COMPONENTS
P2
Q
H
hp
kW
l/min
m
from 1 to 45
from 0,75 to 33
from 30 to 2100
from 7 to 148
CHARACTERISTICS
