Automatic booster sets GI-CV with inverter
Two electric pumps CV (three on request)
N° 2 pressure trasducers 4÷20 mA installed on the discharge manifold that allow the alternating duty - assist run of the electric pumps (alternating duty:
equally distributed according to the actual run-time; assist: according to the request of water)
Inlet manifold with non-return check valves, ball valves and facilities for air feeders
Discharge manifold connected to the electric pumps via ball valves
Pressure gauge
The whole set is assembled on one frame
N° 2 inverters (on the top of the electric pumps) with the following characteristics:
• alarm and protection against dry running
• alarm for low and and maximum pressure
• N.O or N.C, adjustable digital outputs (motor run, alarm, pump control)
• analog inputs 4÷20 mA
MAIN COMPONENTS
P2
Q
H
hp
kW
l/min
m
from 1 to 45
from 0,75 to 33
from 30 to 2100
from 7 to 148
CHARACTERISTICS
