82 / 132
B
A
D
C
DNM
82
Electric submersible pumps SEMISOM series VA
for grey water, vertical discharge
Open impeller
Code
Version
P2 Max
Flow
Ø
solids DNM
Dimensions (mm) Weight
hp kW A
l/min
m
A B C D kg
SEMISOM
190 VA
SMZ190+G/3 230 V 1-phase+float 0,5 0,37 2,45 30 - 150 - 200 9,5 - 4 - 1
5 1"¼ 393 50 225 164 12,8
SEMISOM
320 VA
SMZ320+G/3 230 V 1-phase+float
0,75 0,55
4
30 - 200 - 300 13 - 7,5 - 3 13 1"¼ 418 50 225 164
14,9
STZ320+G/2 400 V 3-phase+float
1,7
16,7
SEMISOM
465 VA
SMZ465+G/3 230 V 1-phase+float
1,5 1,1
6
100 - 300 - 450 16 - 10 - 1 5 2" 484 60 250 172
21,8
STZ465+G/2 400 V 3-phase+float
2,7
23,6
Supplied with
Power cable:
• 5 meters for single-phase versions
• 10 meters for three-phase versions
Capacitor and thermal protector put inaseparate,
easy-accessible, water tight chamber
(single-phase versions)
Mini-contactor put in a separate, easy-accessible
chamber (three-phase versions)
PERFORMANCE DATA 2 poles 60 Hz
