83 / 132
B
A
D
C
DNM
83
Open impeller
Code
Version
P2 Max
Flow
Ø
solids DNM
Dimensions (mm) Weight
hp kW A
l/min
m
A B C D kg
SEMISOM
190 VS
SMZ190
230 V 1-phase
0,5 0,37 2,45 30 - 150 - 200 9,5 - 4 - 1
5 1"¼ 335 50 225 164
10,8
SMZ190+G 230 V 1-phase+float
11
SEMISOM
320 VS
SMZ320
230 V 1-phase
0,75 0,55
4
30 - 200 - 300 13 - 7,5 - 3 13 1"¼ 360 50 225 164
13
SMZ320+G 230 V 1-phase+float
13,2
STZ320
400 V 3-phase
1,7
13
SEMISOM
465 VS
SMZ465
230 V 1-phase
1,5 1,1
6
100 - 300 - 450 16 - 10 - 1 5 2" 440 60 250 172
19,5
SMZ465+G 230 V 1-phase+float
19,7
STZ465
400 V 3-phase
2,7
19,5
Electric submersible pumps SEMISOM series VS
for grey water, vertical discharge
Open impeller
Code
Version
P2
P1 Max
Flow
Ø
solids DNM
Dimensions (mm) Weight
hp kW kW A
l/min
m
A B C D kg
SEMISOM
190 VS
SF190
24 V
DC 0,5 0,37 0,58 24 30 - 150 - 200 9,5 - 4 - 1 5 1"¼ 385 50 225 164 10,2
SEMISOM
320 VS
SF320
24 V
DC 0,75 0,55 0,67 28 30 - 200 - 300 11 - 5,5 - 0,5 13 1"¼ 400 50 225 164 11,6
P1: Max. absorbed power - P2: Nominal power of the motor
Code
Description
02076100
QDC electromechanical
direct starter
(24 V DC versions)
Supplied with
5 meters power cable
Control box containing capacitor
and amperometric protection
(single-phase versions)
PERFORMANCE DATA 2 poles 60 Hz
PERFORMANCE DATA - 24 V DC
ACCESSORIes
